Swing Check Valve

Name: Swing Check Valve
Brand: Karan Valves Pvt. Ltd.

Get a Price/Quote

MOQ : 1 Unit

Swing Check Valve Specification

Pressure
150LB, 300LB, 600LB (PN16-PN100)

Caliber
Standard/Custom

Channels
Single

Diameter
DN25 to DN600

Connection
Flanged

Structure
Swing type

Material
Cast Steel

Power
Manual/Non-powered

Media
Water, Oil, Gas, Steam

Temperature of Media
-29C to 425C (varies by material)

Port Size
1 to 24 (DN25 to DN600)

Flange
ANSI/ASME/DIN Standards

Finish
Anti-corrosive painted/Polished

Application
Pipeline protection, Backflow prevention

Operation
Automatic, Non-return

Face to Face Dimension
ANSI B16.10 standard

Installation Position
Horizontal/Vertical (as applicable)

End Connection
RF/FF/RTJ available

Maintenance
Bolted cover for easy maintenance

Internal Coating
Optional for corrosive service

Disc Material
Stainless Steel, Bronze

Seal Type
Metal to metal or soft seated

Test Standard
API 598

Body Material Options
WCB, CF8, CF8M, etc.

Swing Check Valve Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Units Per Day

Delivery Time
1 Days

Main Domestic Market
All India

About Swing Check Valve

Utilise the offer of an exceptional Swing Check Valve, featured and popular among first-class industrial systems for its astounding reliability. Whether you choose metal-to-metal or soft seated seals, this valve offers a body in WCB, CF8, CF8M, and more to accommodate diverse requirements. Equipped with stainless steel or bronze disc options, it meets ANSI B16.10 face-to-face standards and is tested under API 598. Non-return, automatic operation ensures pipeline protection across applications, from water and gas to oil and steam (up to 425C, depending on material). Maintenance is effortless thanks to a bolted cover, with anti-corrosive finishes and custom port sizes available. Connectivity conforms to ANSI/ASME/DIN standards. Trust India's leading manufacturer and supplier for quality you can depend on.

Competitive Advantages & Application Surface

Swing Check Valves offer first-class backflow prevention, making them highly effective for pipeline protection in water, oil, gas, and steam systems. Their competitive advantages include a robust cast steel body, various sealing options, and easy bolted cover maintenance. With exceptional versatility, these valves feature anti-corrosive finishes and are available with optional internal coatings for corrosive environments. Their swing-type structure and compliance with international standards ensure peak performance across industrial, commercial, and utility surfaces.

Certifications, Transportation, and Domestic Reach

Our Swing Check Valves adhere to renowned international certifications, assuring safety and performance. They are dispatched from key FOB ports nationwide, ensuring swift, reliable transportation and timely arrival at your destination. With efficient dispatching processes, we cater to a broad main domestic market in India, reaching diverse industries and infrastructure sectors. Customers can be confident in the on-time delivery and compliance of every shipment, backed by rigorous testing and documentation.

FAQ's of Swing Check Valve:

Q: How does a swing check valve prevent backflow in pipeline systems?

A: A swing check valve features a disc that automatically swings open to allow forward flow and closes to prevent reverse flow. This mechanism offers reliable non-return operation, safeguarding pipelines from potential contamination and pressure surges by stopping backflow efficiently.

Q: What materials are available for the body and disc of the Swing Check Valve?

A: The Swing Check Valve body is available in WCB, CF8, CF8M, and other robust cast steel options, while the disc is crafted from high-quality stainless steel or bronze. This range enables suitability for varied media and operational conditions.

Q: Where can the Swing Check Valve be installed?

A: The Swing Check Valve is designed for flexible installation, suitable for both horizontal and vertical pipeline orientations, subject to specific application requirements. This adaptability makes it ideal for integration into new systems or retrofit projects.

Q: What is the maintenance process for this Swing Check Valve?

A: Maintenance is straightforward thanks to the bolted cover design, which provides easy access for inspection, cleaning, or replacement of internal components. This feature minimizes downtime and ensures continuous system reliability.

Q: When should an internal coating be utilised with the Swing Check Valve?

A: Opt for the internal coating when dealing with corrosive service media, as it enhances resistance to wear and chemical damage, prolonging the valve's operational lifespan even in the most demanding environments.

Q: What are the primary benefits of using this Swing Check Valve?

A: Primary benefits include exceptional durability, compliance with ANSI/ASME/DIN standards, adaptability to various media and temperatures, and competitive ease of maintenance. The valve delivers first-class pipeline protection and effective backflow prevention.
