8 Inch Basket Strainer

Name: 8 Inch Basket Strainer
Brand: Karan Valves Pvt. Ltd.

Get a Price/Quote

MOQ : 1 Unit

8 Inch Basket Strainer Specification

Diameter
8 Inch

Sealing Type
Gasket Sealing

Tensile Strength
Up to 410 MPa

Coating Type
Epoxy or Paint

Temperature Range
-20C to 200C

Flexibility
Rigid

Yield Strength
Up to 250 MPa

Connection Type
Flanged Ends

Tolerance
1 mm

Thread Type
N/A (Flanged connection)

Product Type
Basket Strainer

Material
Cast Iron / Carbon Steel / Stainless Steel

Connection
Flanged

Shape
Cylindrical

Standard
ASME/ANSI B16.34 / DIN

Surface Treatment
Epoxy Coated / Painted

Outer Diameter
8 Inch (Nominal Bore)

Section Shape
Round

Length
Varies by design

Thickness
12 mm (Body Thickness)

Color
White / Off-White

Usage
Solid-liquid separation in pipelines

Rated Pressure
PN16 / PN25 / Class 150

Application
Water, Oil, Chemical, Gas Pipelines

Material Grade
IS210 Gr FG260 / ASTM A216 Gr WCB / SS316

End Flange Standard
ANSI B16.5 / DIN 2633

Corrosion Resistance
High (with proper material and coating selection)

Installation Orientation
Horizontal / Vertical

Drain/Vent Connection
Provided with NPT/BSP threaded plug

Weight
Approx. 55-75 kg (depending on material/design)

Media Compatibility
Water, Oil, Mild Chemicals, Steam

Filtration Fineness
Down to 100 microns

Body Cover Fastening
Stud-bolted cover for easy maintenance

Basket Type
Removable perforated stainless steel basket

Max Flow Rate
425 m3/hr (varies with media and differential pressure)

Maintenance
Tool-free basket removal possible

Test Pressure
1.5 x Rated Pressure

Leakage Rate
Zero leakage (across joints under rated conditions)

Inspection Port
Available in certain models

8 Inch Basket Strainer Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Units Per Day

Delivery Time
1 Days

Main Domestic Market
All India

About 8 Inch Basket Strainer

Shop Now to experience the preeminent 8 Inch Basket Strainer, engineered for outstanding solid-liquid separation. Featuring an unrivaled removable perforated stainless steel basket, this basket strainer filters down to 100 microns for exceptional performance. Capitalise on optimal efficiency with best price offerings and robust construction in cast iron, carbon steel, or stainless steel. The stud-bolted cover enables easy, tool-free maintenance, ensuring zero leakage and high corrosion resistance. Suitable for water, oil, chemicals, and steam, it meets leading ANSI and DIN standards-making it a top manufacturers' and suppliers' choice across India.

Applications and Usage of the 8 Inch Basket Strainer

The 8 Inch Basket Strainer is ideal for a wide range of applications, excelling in water, oil, chemical, and gas pipeline systems. Suitable for industries such as water treatment plants, chemical processing facilities, and oil refineries, its specific usage lies in capturing solid particulates to protect downstream equipment. This outstanding filtration device ensures operational integrity and longevity for pumps, valves, and other pipeline components in both municipal and industrial environments.

Supply, Packaging, and Logistics Information

Sample availability for the 8 Inch Basket Strainer supports customer evaluation before bulk orders. Packaging is tailored for safe transport, ensuring product integrity on delivery. Flexible payment terms accommodate business needs, while the main domestic market remains India, enabling prompt supply and efficient logistics across regions. Our streamlined packaging and logistics ensure reliable, hassle-free fulfillment for manufacturers, distributors, and end-users alike.

FAQ's of 8 Inch Basket Strainer:

Q: How does the 8 Inch Basket Strainer ensure reliable filtration?

A: The 8 Inch Basket Strainer uses a removable perforated stainless steel basket to filter particles down to 100 microns, ensuring dependable solid-liquid separation and protecting downstream equipment from clogging and damage.

Q: What media can be filtered using this basket strainer?

A: This strainer is compatible with water, oil, mild chemicals, and steam, making it versatile for industrial pipeline applications across several sectors.

Q: Where can the 8 Inch Basket Strainer be installed?

A: The strainer can be installed in both horizontal and vertical pipeline orientations, adapting to various on-site requirements in municipal, chemical, or oil and gas installations.

Q: What is the process of maintaining the basket strainer?

A: Maintenance is simplified with a stud-bolted cover and tool-free basket removal, allowing operators to clean or replace the basket quickly and efficiently without specialized equipment.

Q: What are the benefits of using an 8 Inch Basket Strainer in pipelines?

A: Benefits include outstanding filtration efficiency, zero leakage, high corrosion resistance, long operating life, and easy maintenance-making it a cost-effective and reliable choice for industrial filtration.
